MIL-PRF-58111A(CR)
TABLE I. Pin connections - Continued.
J1 D6001897-5
Mates with MS 3126E20-41S
Connector Pin
Function
A
PVT Hot Mic
B
Remote Xmit Sel 5
E
Panel Light +28V
F
Remote Xmit Sel 4
G
Aux Mic In
J
Panel Light 115V AC
a
Remote Xmit Sel 3
J2 D6001897-6
Mates with MS 3126E20-41SW
Connector Pin
Function
C
Chassis ground
D
Headset audio (HI)
E
Headset audio (LO)
g
Private line PVT-A
P
Private Line PVT-B
R
Interphone Line ICS-A
S
Interphone Line ICS-B
A
Receiver Audio In 1A
B
Receiver Audio In 1B
V
Receiver Audio In 2A
W
Receiver Audio In 2B
U
Receiver Audio In 3A
i
Receiver Audio In 3B
X
Receiver Audio In 4A
Y
Receiver Audio In 4B
k
Receiver Audio In 5A
m
Receiver Audio In 5B
F
Navigation Receiver Audio 1A
G
Navigation Receiver Audio 1B
a
Navigation Receiver Audio 2A
b
Navigation Receiver Audio 2B
n
Navigation Receiver Audio 3A
p
Navigation Receiver Audio 3B
c
Navigation Receiver Audio 4A
H
Navigation Receiver Audio 4B
J
Navigation Receiver Audio 5A
K
Navigation Receiver Audio 5B
s
Navigation Receiver Audio 6A
t
Navigation Receiver Audio 6B
7
