MIL-PRF-58111A(CR)
TABLE I. Pin connections.
J1 D6001897-5
Mates with MS 3126E20-41S
Connector Pin
Function
C
28 VDC Power
D
Power Ground
R
Panel Light +5V
U
Panel Light Power Ground
e
Chassis Ground
H
Chassis Ground
L
Microphone Input (HI)
M
Microphone Input (LO)
K
Wideband Audio Out
b
Interphone Key
c
Key Common
d
Radio Key
f
Transmitter Control #1
g
Transmitter Control #2
h
Transmitter Control #3
r
Transmitter Control #4
t
Transmitter Control #5
X
Logic Select (PVT)
Y
Logic Select (ICS)
Z
Logic Select (XMIT 1)
i
Logic Select (XMIT 2)
j
Logic Select (XMIT 3)
m
Logic Select (XMIT 4)
n
Logic Select (XMIT 5)
N
Transmit Audio Out 1A
P
Transmit Audio Out 1B
S
Transmit Audio Out 2A
T
Transmit Audio Out 2B
V
Transmit Audio Out 3A
W
Transmit Audio Out 3B
k
Transmit Audio Out 4A
s
Transmit Audio Out 4B
p
Transmit Audio Out 5A
q
Transmit Audio Out 5B
6
