MIL-DTL-28837C
4.5.2 Inspection routine. The sample shall be subjected to the inspections specified in table II, in the order shown.
All sample units shall be subjected to the inspection of group I. The sample shall then be divided into two subgroups
and subjected to the inspection for their particular subgroup.
4.5.3 Failures. One or more failures shall be cause for refusal to grant qualification approval.
4.5.4 Disposition of qualification sample units. Sample units which have been subjected to qualification testing
shall not be delivered on any contract or purchase order. The Government reserves the right to retain the sample
units or to require the supplier to furnish the sample units with the qualification inspection report.
TABLE II. Qualification inspection.
Inspection
Requirement paragraph
Test method paragraph
Group I (4 sample units)
Visual and mechanical-----------------------------------------------
3.22 and 3.24
Preconditioning 1/ ----------------------------------------------------
Burn-in 1/ ---------------------------------------------------------------
Electrical characteristics 2/ ----------------------------------------
Conversion loss -----------------------------------------------------
---
Noise figure ----------------------------------------------------------
---
Isolation ---------------------------------------------------------------
---
Conversion compression -----------------------------------------
---
Conversion desensitization --------------------------------------
---
Intermodulation------------------------------------------------------
---
Insertion loss---------------------------------------------------------
---
VSWR -----------------------------------------------------------------
---
RF leakage -----------------------------------------------------------
---
Group II
Subgroup I (2 sample units)
Thermal shock ---------------------------------------------------------
Vibration -----------------------------------------------------------------
Shock --------------------------------------------------------------------
Seal ----------------------------------------------------------------------
Barometric pressure 3/----------------------------------------------
Electrical characteristics 2/ --------------------------------------
3.7
Radiographic inspection 4/ ------------------------------------------
Acceleration 4/ --------------------------------------------------------
Group II
Subgroup II (2 sample units)
Solderability 2/ --------------------------------------------------------
Resistance to solvent 2/ --------------------------------------------
Resistance to soldering heat 2/-----------------------------------
Temperature extreme ------------------------------------------------
Terminal strength 2/ -------------------------------------------------
Moisture resistance---------------------------------------------------
Salt atmosphere 3/---------------------------------------------------
Electrical characteristics 2/ --------------------------------------
1/
Screened only.
2/
As applicable (see 3.1).
3/
When specified (see 3.1).
4/
Space flight mixers only.
4.5.5 Extension of qualification. The extent of qualification of mixer may be extended accordance with appendix A
table A-1. Alternate grouping may be offered by manufactures for consideration by the qualifying activity.
8
